LSW-45-100-5-G-24V

Item No.: LSW-45-100-5-G-24V
TMS Lite

Direct Illumination

LSW SERIES - High intensity, concentrated ring illumination

LED arrays are arranged densely for the light arrays to be concentrated to a spot for extreme bright light.

By using a flexible PCB Board, the product quality and efficiency improves. Flexible boards are able to achieve optimized angle with variation of outer and inner diameter to target a work piece.

Optional diffuser can be added to this LSW light for more even light distribution.

Applications: substrate inspection, label inspection, flat surface, fiducially recognition

Full technical specifications: Click here to download

€600,00
(Price excluding VAT)
Request a quotation?
Type of illumination
Direct
Shape
Ring
Angle
45
Colour
Green
Voltage Input
24V
Size
100
Brand
TMS Lite
Series
LSW

Specification

- Colour Green

- Size 100mm

- Angle 45°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Information

24V DC Input Power

Voltage/Watt                     Current

24V / 14.40 W (Green)     600 mA

LED 525 nm
