foto vooraanzicht LSW-15-090-4-R-24V
tekening schematisch LSW-15-090-4-R-24V
schema lichtval LSW-15-090-4-R-24V
foto zijaanzicht LSW-15-090-4-R-24V
foto onderaanzicht LSW-15-090-4-R-24V

LSW-15-090-4-R-24V

Item No.: LSW-15-090-4-R-24V

Direct Illumination

LSW SERIES - High intensity, concentrated ring illumination

LED arrays are arranged densely for the light arrays to be concentrated to a spot for extreme bright light.

By using a flexible PCB Board, the product quality and efficiency improves. Flexible boards are able to achieve optimized angle with variation of outer and inner diameter to target a work piece.

Optional diffuser can be added to this LSW light for more even light distribution.

Applications: substrate inspection, label inspection, flat surface, fiducially recognition

Full technical specifications:Click here to download

517,00
(Price excluding VAT)
Type of illumination
Direct
Shape
Ring
Angle
15
Colour
Red
Voltage Input
24V
Size
90
Brand
TMS Lite
Series
LSW

Specification

- Colour Red

- Size 90mm

- Angle 15°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Information

24V DC Input Power

Voltage/Watt                     Current

24V / 7.92 W (Red)       330 mA

LED 630 nm
