LSQF-00-033-1-R-24V

Name: LSQF-00-033-1-R-24V
Brand: TMS Lite
Price: 367.00 EUR
Availability: InStock

Item No.: LSQF-00-033-1-R-24V

Direct Illumination

LSQF STACKABLE SERIES - High density, concentrated light

LSQF stackable lighting offers 4 different angles in 3 different sizes. By using a combination of different lights, multiple lighting techniques can be applied during inspection. Can be triggered individually or simultaneously.

LED arrays are arranged to provide concentrated light. The different LED angle allow small or wider spot illumination.

Applications: flat surface, fiducially recognition, label inspection, substrate inspection, 3S & 5S

Diffuser

Extension cable

Polarizer

€367,00

(Price excluding VAT)

Request a quotation?

EAN

SKU

Type of illumination

Direct

Shape

Square

Angle

Colour

Red

Voltage Input

24V

Size

Series

LSQF

More TMS Lite | More Illumination

Description

Specification

- Colour Red

- Size 33mm

- Angle 0°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical information

24V DC Input Power

Voltage/Watt Current

24V / 0.72 W (Red) 30mA

LED 630 nm

LSQF-00-033-1-R-24V

Recommended products for LSQF-00-033-1-R-24V

EXT-24V-F-5M
