Item No.: 167.0689

Coaxial Illumination

HCAS SERIES - Uniform high power coaxial light

HCAS series is a high power coaxial illumination with heat sink. The light projected from the light source is reflected by 45° half mirror to provide light in line with the camera.

Applications: surface inspection and alignment, wafer, metal surface, film, LCD and glass, pattern on PCB

Full technical specifications: Click here to download

2.452,00
(Price excluding VAT)
EAN
7435845065083
Type of illumination
Coaxial
Shape
Coaxial
Angle
0
Colour
White
Voltage Input
24V
Size
70
Brand
TMS Lite
Series
HCAS

Specification

- Colour White

- Size 70mm

- Angle 0°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical Information

24V DC Input Power

Voltage/Watt                   Current

24V / 18.0 W (White)      750mA

Alternate products for HCAS2-00-070-X-W-24V
