DFR4-00-130-1-R-24V
DFR4-00-130-1-R-24V
DFR4-00-130-1-R-24V
DFR4-00-130-1-R-24V
DFR4-00-130-1-R-24V

DFR4-00-130-1-R-24V

Item No.: 167.0450

Diffused Ring Illumination

DFR SERIES - Diffused angular ring illumination

DFR Series provide diffused even illumination over a surface. A conical illumination surface makes it possible to illuminate a work piece from almost any angle.

Applications: printed character on IC chips, PCB component, printing on caps and wafer OCR inspection

Full technical specifications: Click here to download

Extension cable

409,00
(Price excluding VAT)
EAN
7435842086074
SKU
DFR4-00-130-1-R-24V
Type of illumination
Diffused
Shape
Ring
Angle
0
Colour
Red
Voltage Input
24V
Size
130
Brand
TMS Lite
Series
DFR

Specification

- Colour Red

- Length 130mm

- Angle 0°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical Information

24V DC Input Power

Voltage/Watt                  Current

24V / 7.20 W (Red)       300 mA

LED 620 nm OSRAM
