DCM PLA2026A-470i/AD

DCM PLA2026A-470i/AD, Direct High Power Bar Light

DCM PLA2026A-470i/AD - High power bar illumination DCM Sistemes

The PLA series is a high power bar illumination for application that requires high intensity illumination. Thanks to their small size and light weight, they are ideal for operating with robots. This bar light provides great contrast and highlight textures, reliefs and fissures of illuminated objects.

The built-in iBlueDrive technology controller gives you the possibility to connect this light direct to the camera or triggersignal in continuous-, dim- or strobe mode, therefore there is no more need for an external controller.

The strobe mode factory preset is 47 pulses per second, this can be set to a maximum of 5000 pulses per second with a USB program cable (sold separately) and the iBueDrive control manager software. You can find more information about iBlueDrive technology here.

iBlueDrive supports: NPN, PNP, TLL, Continuous en Dim

Applications: Robot vision, injection mold inspection, assembly inspection

Full technical specifications: Click here to download

Manufactured in Europe
